DBS-20C = weight: 15 lbs, dimensions: 13.5” height.
DBS-24C = weight: 19 lbs, dimensions: 14.75” height.
| Pipe Size | Nominal Wall Thickness | SDR | Gap Stop | % Max Squeeze |
| 1/2" CTS | 0.090 0.104 | 7 6 | 0147 0.172 | 22 21 |
| 1/2" IPS | 0.090 | 9.3 | 0.155 | 14 |
| 3/4" CTS | 0.090 | 9.7 | 0.155 | 18 |
| 3/4" IPS | 0.095 | 11 | 0.155 | 25 |
| 1" CTS | 0.090-0.101 | 11-12.5 | 0.155 | 29 |
| 1" IPS | 0.119 0.140 | 11 9.3 | 0.210 0.234 | 22 27 |
| 1-1/4" CTS | 0.090 0.121 | 15 11 | 0.155 0.210 | 17 19 |
| 1-1/4" IPS | 0.151-0.166 0.178 | 10-11 9.3 | 0.270 0.288 | 27 25 |
| 1-1/2" IPS | 0.173 | 11 | 0.288 | 22 |
| 2" IPS | 0.216 | 11 | 0.347 | 25 |
For replacement parts, contact sales@groebner.com.
The redesigned Mustang Model DBS-20C Mid-Range Squeeze Tool
accommodates pipe sizes from 1/2” CTS to 2” IPS maximum. The DBS-20C can be
used on service pipe up to medium size distribution pipe with ease and safety.
The lower jaw has two sets of gap stops to accommodate two pipe sizes of your
choice.
THE DBS-24C is similar to the DBS-20C, but uses a quad-bar
design that accommodates pipe sizes from 1/2” CTS to 2” IPS maximum. The
DBS-24C can be used on service pipe up to medium size distribution pipe with
ease and safety. The lower jaw has four sets of gap stops to accommodate four
pipe sizes of your choice.
Features include a larger, heavy-duty frame designed to
withstand the greater force needed to squeeze today’s PE pipe, while retaining
the quad-bar jaw design for greater contact area.
A high-strength power screw and thrust bearing with grease
fittings for lubrication, as well as a provision for using a SEG-30 Grounding
Rod for static electric grounding, completes the package.
The redesigned Mustang Model DBS-20C Mid-Range Squeeze Tool
accommodates pipe sizes from 1/2” CTS to 2” IPS maximum. The DBS-20C can be
used on service pipe up to medium size distribution pipe with ease and safety.
The lower jaw has two sets of gap stops to accommodate two pipe sizes of your
choice.
THE DBS-24C is similar to the DBS-20C, but uses a quad-bar
design that accommodates pipe sizes from 1/2” CTS to 2” IPS maximum. The
DBS-24C can be used on service pipe up to medium size distribution pipe with
ease and safety. The lower jaw has four sets of gap stops to accommodate four
pipe sizes of your choice.
Features include a larger, heavy-duty frame designed to
withstand the greater force needed to squeeze today’s PE pipe, while retaining
the quad-bar jaw design for greater contact area.
A high-strength power screw and thrust bearing with grease
fittings for lubrication, as well as a provision for using a SEG-30 Grounding
Rod for static electric grounding, completes the package.
